Insert 2 jumpers on PL10 pin 2-3 and 5-6 (leftmost pin is 1) for secondary MIDI IN. JP8: Use USB for power supply (may result in noise)ĭefault jumper setting: Insert JP6.

JP7: Swell on AVR analog input PA7 (do not use) JP6: Swell on AVR analog input PA2 (default) JP5: Swell on Analog Input 12 (do not use) JP3: Digital Ground (Probe Connection), both pins JP2: 5V DC input on PL10/PL12 (wall wart plug) if inserted JP1: Analog Ground (Probe Connection), both pins P元3: Bluetooth Module (BLE, not used yet) P元2: 4pin USB header to HX3.5 Extension Board P元1: 3 pin header Footswitch Rotary control P元0: 3 pin header Swell Pedal (FC-7 compatible) PL29: Preamp control outputs, various control signals PL28: 1/4" jack Swell Pedal (FC-7 compatible) PL27: 1/4" jack Footswitch Rotary control PL26: Buttons/Switches 8 to 15 (default Common Presets or Vibrato Buttons, Reverb, Bass On Amp, Split) PL25: Buttons/Switches 0 to 7 (default Percussion, Vib On, Rotary control) PL23: Analog inputs 12 to 23, (default lower drawbars) PL22: Analog inputs 0 to 11 (default upper drawbars) PL13: Scan Board (Scan16-Strip, Scan61-Inline, OrganScan61 or Bass25) PL10: DC input, 5V or 9.12V/500mA, plus on center

PL5: Stereo Audio Mixer Input center = GND
#Vib ribbon instruction manual pdf
HX3.5 Part/Connector designators (available as PDF also, see our Documentation and Update Server)
#Vib ribbon instruction manual manual
A complete user manual is available as PDF for download on our Update Server.
#Vib ribbon instruction manual zip file
Updates in ZIP file (named HX35_Update_5xxx.zip) contain HX3.5 Manager application as well as DSP firmware, sound bank(s), FPGA configuration images and scan drivers.
